GE IS200ERIOH1AAA Exciter Regulator I/O Board Mark VI EX2100

GE IS200ERIOH1AAA is the Exciter Regulator I/O (ERIO) board developed for GE Mark VI Speedtronic turbine control and EX2100 digital excitation system. It serves as the discrete signal interface between the excitation controller and field devices, collecting digital input status and driving relay outputs for excitation interlock and protection logic.

This board comes with 16 configurable digital input channels and 16 relay output points. It communicates with DSP and EROC boards via VME backplane bus, with on-board status LEDs for fast fault inspection. It is widely used as spare replacement parts for power plant generator excitation cabinet maintenance and retrofit projects.

Main Specifications

1. Brand: GE; Model: IS200ERIOH1AAA; Type: Exciter Regulator I/O Board (ERIO)
2. Compatible System: Mark VI / Mark VIe Turbine Control & EX2100 Excitation System
3. Channels:16 digital inputs (0-30VDC, configurable logic), 16 relay outputs
4. Relay Rating: 2A @ 250VAC / 30VDC resistive load; Power consumption: 10W
5. Bus: VME backplane bus; Indicator: LED status indicators for each channel
6. Operating Temp: -40℃ ~ +85℃; Humidity:5%~95% non-condensing
7. Supply Status: Legacy spare I/O board for EX2100 excitation cabinet

Core Functions

1. Collect field discrete signals including excitation breaker status, interlock and fault feedback signals.
2. Drive relay outputs to control excitation contactors, alarms and protection trip circuits.
3. Exchange real-time digital I/O data with DSP and EROC control boards over VME backplane.
4. Software configurable positive / negative logic for digital input channels to match field wiring.
5. Onboard LED indicators to show real-time channel status for convenient on-site troubleshooting.
6. Standard VME double-height board form factor for direct rack replacement during overhaul.

Application Scenarios

1. GE Mark VI gas turbine and steam turbine control cabinets in thermal power plants.
2. EX2100 generator excitation control system for synchronous generator excitation regulation.
3. Replacement of defective ERIO I/O boards in existing EX2100 excitation racks.
4. Spare parts inventory for power plant electrical and automation maintenance teams.
5. Retrofit and upgrade of legacy GE Speedtronic Mark VI turbine excitation control systems.
6. Excitation protection interlock control for combined-cycle power generation units.

FAQ

1. Q: What is GE IS200ERIOH1AAA?
   A: It is ERIO exciter regulator I/O board for Mark VI and EX2100 excitation system, handling discrete signal input and relay output for excitation interlock control.
2. Q: What does ERIO stand for?
   A: ERIO stands for Exciter Regulator Input/Output board, the dedicated digital I/O interface card for GE EX2100 excitation cabinet.
3. Q: What is the output type?
   A: It adopts dry contact relay outputs, rated 2A, suitable for driving excitation cabinet auxiliary circuits and alarm signals.
