CSP CSR70是数字轨道电路控制专用电源模块（DM TCC），采用直流母线输入架构，支持N+1冗余并联备份方案，为铁路轨道信号回路提供不间断稳压供电。模块内置完善的硬件保护与故障监测电路，适配轨道交通信号安全控制标准。

CSP CSR70 is a dedicated power supply module for digital track circuit control (DM TCC). It uses DC bus input and supports N+1 redundant parallel backup, delivering stable uninterrupted power to railway track signal loops. It integrates comprehensive hardware protection and fault monitoring complying with rail signaling safety standards.

具备过压、过流、短路保护以及故障告警输出功能，安装于铁路信号控制柜内。该型号多用于存量轨道电路改造、大修替换，属于轨道交通信号系统稀缺维修备件，对供电连续性和安全等级要求极高。

It provides overvoltage, overcurrent and short-circuit protection plus status alarm relay output. Mounted inside railway signaling cabinets, this module is mostly used for overhaul and retrofit of legacy track circuits. It is a critical spare with strict requirements on power continuity and functional safety.

Main Specifications 技术参数

• 1. Product Series / 产品系列：CSP Railway Track Circuit Power Supply

• 2. Part Numbers / 型号编码：CSR70

• 3. Function Type / 类型：数字轨道电路控制电源模块

• 4. Key Features / 特性：DC bus input, N+1 redundant backup, safety alarm, multi-protection

• 5. Mounting / 安装：信号机架导轨安装，轨道交通控制柜适配

Core Functions 核心功能

• 1. 轨道信号回路稳定供电，保障轨道电路检测信号持续输出。
  Stable power feeding for track loops to maintain track detection signal integrity.

• 2. N+1冗余并联，单台故障不中断整个轨道电路供电。
  N+1 parallel redundancy, single unit failure will not cut off track circuit power.

• 3. 多重电气保护，短路、过流、过压时快速锁止输出，防止信号设备损坏。
  Multi-layer protection, shut down rapidly on short circuit, over-current and over-voltage.

• 4. 故障状态干接点告警，上传至信号联锁系统做故障提示。
  Dry contact fault alarm for reporting status to interlocking control system.

• 5. 宽温工业设计，适应轨旁控制柜温差、震动等恶劣工况。
  Wide temperature rugged design for vibration and temperature fluctuation beside tracks.

Application Scenarios 应用场景

• 1. 铁路数字轨道电路信号柜CSR70电源模块老化损坏同型号替换。
  Like-for-like replacement of failed CSR70 power units inside railway signal cabinets.

• 2. 既有线路轨道信号系统大修、定期备件储备。
  Spare stocking for scheduled overhaul and maintenance of existing rail signaling lines.

• 3. 轨道电路改造项目，保留原有DM TCC控制架构，更换供电单元。
  Retrofit projects keeping original DM TCC logic with new identical power modules.

• 4. 信号系统冗余扩容，新增轨道回路配套冗余电源模块。
  Redundancy expansion for new track detection loops in signaling racks.

• 5. 海外轨道交通信号项目备件供货，配套机架调试与回路测试。
  Overseas rail signaling spare supply with cabinet commissioning and loop testing.
