ICS TRIPLEX T9481 Trusted 8 Channel Isolated Analog Output Module

ICS TRIPLEX T9481 is an 8-channel isolated analog output module for the Trusted safety instrumented system. It receives digital control commands from the safety processor and converts signals into 4-20mA analog outputs to control field valves, actuators and regulating devices, with built-in continuous channel diagnostic functions.

This module supports simplex, dual and TMR triple modular redundant configurations to meet IEC61508 SIL3 safety requirements. It supports hot swap on Trusted backplane without interrupting safety system operation, widely supplied as spare parts for maintenance and replacement of ESD and process safety control systems.

Main Specifications

1. Brand: ICS TRIPLEX (Rockwell Automation); Model: T9481; Series: Trusted; Type: Analog Output Module
2. Channels: 8 isolated analog output channels; Signal type: 4-20mA current output
3. Backplane supply:18~32VDC; Power consumption: approx 4.6W
4. Resolution: 16-bit D/A conversion; Per-channel galvanic isolation
5. Operating Temp: -20℃ ~ +60℃; Protection: IP20, cabinet mounting
6. Redundancy: Simplex, dual, TMR triple redundant; Hot swappable
7. Supply Status: Industrial spare module for existing Trusted SIS system overhaul

Core Functions

1. Convert safety processor digital commands into 4-20mA analog signals to regulate field control valves and actuators.
2. Individual channel galvanic isolation to suppress field interference and prevent cross-channel fault propagation.
3. Built-in continuous on-board diagnostics to detect wire break, short circuit and report fault status to safety CPU.
4. Compatible with simplex, dual and TMR redundant architecture to achieve IEC61508 SIL3 safety integrity level.
5. Hot swap function, replace defective module while the safety instrumented system remains running.
6. Standard Trusted rack mounting, convenient disassembly and maintenance for safety control cabinets.

Application Scenarios

1. Safety instrumented system analog output control for chemical and petrochemical plants.
2. Emergency shutdown system and fire & gas system regulating valve control.
3. Power plant boiler and turbine safety protection actuator analog adjustment.
4. Replacement of faulty analog output modules for running Trusted safety platforms.
5. Spare parts inventory for factory maintenance teams of SIL3 safety automation systems.
6. Retrofit and upgrade of legacy oil & gas process safety control cabinets.

FAQ

1. Q: What is ICS TRIPLEX T9481 used for?
   A: It is an 8-channel isolated analog output module for Trusted SIS system, outputting 4-20mA signals to control field regulating valves for safety process control.
2. Q: Does T9481 support hot swap?
   A: Yes, it supports hot swap on Trusted backplane without system shutdown during module replacement.
3. Q: What safety level can T9481 achieve?
   A: When configured in TMR architecture, it can meet IEC61508 SIL3 safety integrity level requirements.
