LSU-112DG 100031593.10 Linear Servo Motor

LSU-112DG, part number 100031593.10, is a high force iron core linear servo motor. It adopts direct drive design without mechanical transmission components, delivering high acceleration, high precision and stable thrust for high-speed automated positioning platforms.

This linear motor matches dedicated servo drives for closed-loop position control. It features strong electromagnetic thrust and good thermal dissipation performance. Widely used as spare replacement parts for semiconductor equipment, inspection machines and precision automation production lines.

Main Specifications

1. Brand: Industrial Linear Motor; Model: LSU-112DG; Part No:100031593.10; Type: Iron Core Linear Servo Motor
2. Structure: Iron core stator and moving coil; Direct drive, no ball screw or gear mechanism
3. Core Functions: High precision linear positioning, high speed & high acceleration motion, constant thrust output
4. Cooling Method: Air cooling; Position Feedback: External linear encoder for closed loop control
5. Features: High thrust density, fast dynamic response, low maintenance, high repeat positioning accuracy
6. Application Axis: Single or multi-axis gantry systems, precision inspection and handling equipment
7. Supply Status: Industrial spare part for precision automation equipment maintenance and replacement

Core Functions

1. Direct linear drive eliminates backlash caused by ball screw and coupling to achieve ultra-precise positioning.
2. High thrust iron core design supports rapid acceleration and high-speed reciprocating motion for high throughput equipment.
3. Closed-loop control with linear encoder realizes high repeat accuracy and stable motion under variable load.
4. Air cooling structure ensures continuous operation and restrains temperature rise during long-time high-load movement.
5. Fewer wearing mechanical parts reduce downtime and maintenance cost compared with traditional rotary servo system.
6. Compatible with mainstream servo drives to build multi-axis high-speed motion control platform for precision automation.

Application Scenarios

1. High-speed precision positioning axis for semiconductor equipment, visual inspection and electronic handling machines.
2. Fault linear motor replacement and routine maintenance of existing direct drive automation platforms.
3. Precision production line upgrading and technical transformation for high-speed pick & place equipment.
4. Emergency replacement for linear motor breakdown to resume high-speed automatic processing.
5. Spare parts stocking for maintenance teams maintaining direct-drive precision automation machines.
6. Aftermarket spare supply for gantry system integration and precision automation equipment retrofitting projects.

FAQ

1. Q: Does LSU-112DG 100031593.10 linear motor include linear encoder?
   A: The encoder is a separate component, not integrated inside this linear motor and needs to be configured separately.
2. Q: What are typical linear motor failure symptoms?
   A: Abnormal overheating, thrust loss, motor vibration, coil short circuit, encoder signal loss.
3. Q: How to complete commissioning and diagnosis?
   A: Check motor cable and encoder wiring, configure servo drive parameters, run jog test and verify position feedback stability.
