LANTRONIX 080‑580‑001‑R Xpress‑DR Industrial Device Server

The LANTRONIX 080‑580‑001‑R is a DIN‑rail mount industrial serial‑to‑Ethernet device server for factory and process automation sites. It converts bidirectional RS‑232 / RS‑485 serial data into 10/100Mbps Ethernet TCP/IP communication, enabling legacy serial PLCs, instruments and field controllers to connect directly to plant LAN and SCADA monitoring systems without hardware redesign.

This compact DIN‑rail unit supports Modbus RTU‑TCP protocol conversion, virtual COM port and serial tunneling modes. It accepts wide‑range AC/DC industrial power and carries Class I Div 2 hazardous‑location certification. Configuration and firmware ｕｐｄａｔｅ are completed via built‑in web‑page interface. Original production has been discontinued. It is widely supplied as aftermarket spare parts for industrial communication cabinet maintenance and automation‑system retrofit projects.

Main Specifications

1. Brand:Lantronix; Model:080‑580‑001‑R; Type:Xpress‑DR DIN‑Rail Industrial Device Server
2. Network Interface:10/100Base‑TX auto‑sensing Ethernet, RJ45 connector
3. Serial Interface:Combined RS‑232 / RS‑485 terminal block, baud‑rate 300‑921600 bps
4. Power Supply:9‑30 VDC / 9‑24 VAC wide‑range industrial power input
5. Supported Protocols:TCP, UDP, DHCP, Telnet, HTTP, Modbus RTU‑TCP, SNMP
6. Certification:Class I Div 2 Groups A,B,C,D T4A hazardous‑location approval
7. Supply Status:Original production discontinued, available as tested surplus or refurbished spare parts

Core Functions

1. Perform bidirectional protocol conversion between RS‑232/RS‑485 serial signals and Ethernet TCP/IP packets for legacy serial‑based field automation equipment.
2. Support Modbus RTU to Modbus‑TCP conversion, virtual COM port, serial tunneling and socket server/client operating modes.
3. Provide built‑in web‑server for remote parameter configuration, status monitoring and firmware upgrade over Ethernet local network.
4. DIN‑rail compact form factor allows direct installation inside industrial control cabinets for harsh factory‑floor environmental conditions.
5. Multi‑color LED indicators display Ethernet link status, serial activity and fault alarm for convenient on‑site maintenance diagnosis.
6. Serve as standalone serial‑IP conversion gateway for process instruments, drives and legacy serial controllers in industrial automation systems.

Application Scenarios

1. Factory automation, process plants, marine and hazardous‑location sites requiring serial‑to‑Ethernet conversion for legacy serial field devices.
2. Spare device‑server replacement and routine maintenance of existing automation cabinets equipped with Lantronix Xpress‑DR series hardware.
3. Technical renovation and network‑communication upgrade of aging serial‑based industrial control and monitoring systems.
4. On‑site troubleshooting and replacement of faulty communication gateways on continuously running industrial production equipment.
5. Spare‑parts stocking for system integrators and maintenance contractors supporting legacy Lantronix industrial networking hardware platforms.
6. Global aftermarket spare supply for technical teams maintaining industrial automation systems with serial‑to‑Ethernet conversion requirements.

FAQ

1. Q:Can Lantronix 080‑580‑001‑R work as standalone unit?
   A:It is an independent DIN‑rail gateway, can run standalone after power supply and network‑serial wiring configuration.
2. Q:What are typical failure symptoms?
   A:Serial‑Ethernet data forwarding interruption, virtual COM disconnection, loss of web‑configuration page access may appear.

3. Q:How to configure parameters?
   A:Configuration, monitoring and firmware ｕｐｄａｔｅ are completed via built‑in web browser interface over Ethernet network.
