Bently Nevada 330780‑50‑00 Eddy Current Proximity Transducer

The Bently Nevada 330780‑50‑00 is a 3300 XL series eddy‑current proximity transducer. It performs non‑contact measurement of shaft vibration, radial clearance and rotor position of rotating machines and outputs linear voltage signals for continuous online condition monitoring.

This matched assembly includes probe, extension cable and proximitor driver with excellent temperature stability and linear range. It is fully compatible with the Bently 3500 monitoring rack. Original production has been discontinued. It is widely stocked as aftermarket spare parts for power, oil & gas and petrochemical machinery protection systems.

Main Specifications

1. Brand: Bently Nevada; Model:330780‑50‑00; Type:3300 XL Eddy‑Current Proximity Transducer
2. System Composition:Probe, factory‑matched extension cable and proximitor signal converter
3. Measurement Principle:Eddy‑current non‑contact sensing for displacement and vibration monitoring
4. Output Signal:Linear negative DC voltage, designed for 3500 series monitoring modules
5. Key Features:Wide linear range, high stability, impedance‑matched cable, strong noise immunity
6. Typical Equipment:Turbines, centrifugal compressors, large pumps and critical rotating machinery
7. Supply Status:Original production discontinued, available as tested surplus or refurbished spare parts

Core Functions

1. Carry out non‑contact real‑time measurement of radial vibration and shaft gap of rotating equipment.
2. Convert tiny mechanical displacement changes into stable linear voltage signals for rack data acquisition.
3. Catch early mechanical faults such as rotor unbalance, shaft rubbing and bearing clearance anomalies.
4. Use factory‑calibrated matched cables to minimize signal attenuation and electromagnetic interference.
5. Cooperate with 3500 monitoring racks to realize machinery alarm and safety interlock protection.
6. Provide long‑term vibration trend data for predictive maintenance and equipment health evaluation.

Application Scenarios

1. Online vibration and displacement monitoring for steam turbines, compressors and large process pumps.
2. Spare transducer replacement and daily maintenance of existing Bently 3300XL and 3500 systems.
3. Technical renovation and reliability upgrading of aging rotating machinery protection cabinets.
4. On‑site troubleshooting and replacement of faulty proximity transducer sets on key production units.
5. Spare‑parts stocking for system integrators and machinery condition monitoring contractors.
6. Global aftermarket spare supply for technicians maintaining obsolete Bently Nevada vibration monitoring hardware.

FAQ

1. Q:Can I mix probe, cable and proximitor from different sets?
   A:No, each set is factory calibrated and matched; random mixing will affect measurement accuracy.
2. Q:Which monitoring system does it work with?
   A:It is designed to work with Bently Nevada 3500 series vibration monitoring racks.

3. Q:Is this proximity transducer still in original production?
   A:Bently Nevada has stopped manufacturing this model, only tested surplus and refurbished spare units are available.
