B&R 7EX484 Ethernet POWERLINK Bus Controller Module

The B&R 7EX484 is an Ethernet POWERLINK bus controller module developed for the B&R System 2003 automation platform. It acts as the central network manager, establishing real-time industrial Ethernet communication to coordinate servo drives, I/O modules and other field nodes within the automation system.

Equipped with four independent POWERLINK communication ports, this module supports flexible network topologies for synchronous motion control. Featuring robust industrial hardware design and built-in diagnostic LEDs, it delivers stable deterministic data transmission and is widely used for machine retrofitting and spare part replacement.

Main Specifications

• Brand: B&R Industrial Automation

• Model: 7EX484

• Series: System 2003 Controller Platform

• Communication Standard: Ethernet POWERLINK

• Interfaces: 4 x POWERLINK Ethernet ports

• Power Supply: 24 VDC nominal input

• Transmission Rate: Up to 100 Mbps

• Operating Temperature: -20°C ~ +60°C

• Protection Class: IP20 for cabinet installation

• Approximate Weight: 0.42 kg

Core Functions

• Operate as POWERLINK managing node for real-time motion network

• Synchronous control and data exchange with servo drives and remote I/O

• Support daisy-chain and star network topology configurations

• Deterministic high-speed communication for multi-axis synchronization

• Onboard LED indicators for network status and fault diagnosis

• Electrical isolation to suppress industrial electromagnetic interference

• Seamless hardware integration with B&R System 2003 rack system

• Support network monitoring and node fault detection functions

• Convenient configuration via B&R Automation Studio software

• Continuous stable operation under long-term production conditions

Application Scenarios

• Packaging machinery multi-axis synchronous motion control systems

• Plastic injection molding and extrusion automation equipment

• Printing machinery register and web tension control cabinets

• Textile production line high-speed motion control equipment

• Automated assembly and handling machinery control systems

• CNC machine tool peripheral motion network control

• Food and beverage processing line automation projects

• Legacy B&R System 2003 equipment renovation and spare parts

• Robotic auxiliary axis synchronous control systems

• General industrial machinery high-precision motion control solutions
