PROSOFT SST‑PB3‑CLX PROFIBUS DP Communication Module

The SST‑PB3‑CLX is a PROFIBUS DP slave/master communication interface module designed for Allen‑Bradley ControlLogix PLC racks. It connects the ControlLogix backplane to PROFIBUS DP field devices and realizes high‑speed cyclic data exchange between the PLC and distributed field peripherals.

This rack‑mounted module supports standard PROFIBUS DP protocol and comes with configuration software for data mapping and diagnostics. Original production has been discontinued. It is widely stocked as aftermarket spare parts for factory automation, packaging and process production line control cabinet maintenance and network upgrading.

Main Specifications

1. Brand:PROSOFT; Model:SST‑PB3‑CLX; Type:ControlLogix PROFIBUS DP Communication Module
2. Compatible Platform:Allen‑Bradley ControlLogix 1756 series PLC backplane
3. Fieldbus Standard:PROFIBUS DP, supports master or slave operating mode
4. Data Exchange:Cyclic real‑time I/O data transmission and acyclic parameter diagnosis
5. Configuration:PC software for bus topology setup, data mapping and fault monitoring
6. Installation:Directly plug into standard 1756 ControlLogix rack slots
7. Supply Status:Original production discontinued, available as tested surplus or refurbished spare parts

Core Functions

1. Act as a PROFIBUS DP master or slave gateway for ControlLogix PLC automation systems.
2. Transmit real‑time input and output data between the PLC and PROFIBUS‑capable drives, sensors and remote I/O.
3. Map PROFIBUS process data directly into the ControlLogix controller tag memory area.
4. Provide bus diagnostic information, slave status and communication fault codes for troubleshooting.
5. Support acyclic read/write access to device parameters for commissioning and maintenance.
6. Serve as the PROFIBUS fieldbus connection bridge for legacy Rockwell ControlLogix automation racks.

Application Scenarios

1. Automated production lines, packaging machinery, material handling systems and process industry control plants.
2. Spare communication module replacement and routine maintenance of existing ControlLogix PROFIBUS network cabinets.
3. Technical renovation and fieldbus networking upgrade of aging Rockwell PLC automation systems.
4. On‑site troubleshooting and replacement of faulty PROFIBUS interface modules on continuous production units.
5. Spare‑parts stocking for system integrators and Rockwell / PROFIBUS automation maintenance contractors.
6. Global aftermarket spare supply for technicians maintaining obsolete SST fieldbus communication hardware.

FAQ

1. Q:Which PLC rack does SST‑PB3‑CLX fit into?
   A:It is designed exclusively for Allen‑Bradley ControlLogix 1756 chassis and cannot be used for other PLC families.
2. Q:Does this module support both PROFIBUS master and slave modes?
   A:Yes, it can be configured either as PROFIBUS DP master or slave according to project requirements.

3. Q:Is this PROFIBUS communication module still in original production?
   A:The manufacturer has stopped manufacturing this model, only tested surplus and refurbished spare units are available.
