DS200DCFBG1B

DS200DCFBG1B

The DS200DCFBG1B board also has three fuses to protect the power supply.When replacing the DS200DCFBG1B board, make sure the power to the drive is turned off.Failure to follow this procedure may result in serious injury.Disconnect all cables from the DS200DCFBG1B board and push back on the plastic bracket to release the board from its bracket.Orient the new board so it is oriented the same way as the old board and place it into the bracket.You can then reconnect the cables to the board according to the labels.After that, you need to adjust the EE parameters of the board to get the voltage feedback offset.

The DS200DCFBG1B is a power strip designed and manufactured by General Electric as part of its Mark V SPEEDTRONIC series.The DS200DCFBG1B board is versatile and can be used in many IGBT driver applications including: AC2000, CB2000, DC200, EX2000, FC2000, GF2000 and ME2000.The DS200DCFBG1B board is designed to accept 38 and 115 VAC input power from a CPT or control power transformer.The DS200DCFBG1B board then provides control-level power to its drives and 115 VAC power to its cabinet fans.The DS200DCFBG1B board contains many circuits, including: motor field power supply circuits, circuits for monitoring the AC line and DC motor signals, control stage power supplies, and drive circuits for the motor field SCR gate pulses.There are five test points on the DS200DCFBG1B board, allowing users to check the voltage signal, voltage signal status and DCFB board common line
