DS200AAHAG2A

DS200AAHAG2A is a MARK V LM Speedtronic ARCNET HUB LAN driver board. The board was originally created by GE, but now it is a legacy series module and no longer receives any support from GE. Nevertheless, AX Control will indeed attempt to retain inventory of the board when there is available surplus in the market.

ABB 3ASC25H214 DATX130（5）.jpg

DS200AAHAG2A, also known as ARCNET Connection Board (AAHA). It is designed as part of the control panel in the Mark V system. The AAHA board can connect external devices to the control engine, which is a core part of<R>. It uses ARCNET connection to complete this operation< R> The core actually uses two of these boards to achieve slightly different purposes. An AAHA board is used to facilitate stage linking between different operator interfaces and<R>cores. Another AAHA board is used to grant<R>core communication to the COREBUS network. Making this connection will facilitate communication between the control engine and the I/O cores in the<R>kernel. The board is also connected to the PANA board using APL connectors.

VMIVME-7807.蒋娜.202108270859506 (4).jpg

The characteristics of DS200AAHAG2A (AAHA) are as follows:

Two connection ports.

The other two ports labeled P1 and P2 on the right are ARCBNC-B and ARCBNC-A ports.

VMIVME-1150-123L.20200713_173228 (12).jpg

Below the P1 connector is the 2PL connection. The bottom right corner of the board is an APL 10 pin connector used to provide a communication link between the AAHA board and the board containing the ARCNET driver in the<R>kernel.
