Products Description
ABB 3BHE037864R0104
ABB 3BHE037864R0104
ABB 3BHE037864R0104
Central Processing Unit Module Automation Control System
3BHE037864R0104 Central Processing Unit Module Automation Control System
Power supply and protection:
Ø Power supply: Dual power redundant input, DC (9-36) V, typical DC24V, power consumption less than 4W, with DC1500V voltage isolation and reverse protection function, industrial terminal interface
Ø Relay alarm output: Fiber optic link fault and power supply fault alarm output, contact capacity: DC48V/1A, industrial terminal interface
Mechanical characteristics:
*External dimensions: 132mm× 105mm× 52mm
*Shell: IP30 protection level, corrugated aluminum reinforced casing
*Installation method: 35mm DIN rail installation
*Net weight: 800g
Work environment:
*Working temperature: -10-70 ℃ (-40~+85 ℃ wide temperature optional)
*Relative humidity: ≤ 90% (non condensing)
*Storage temperature: -40~80 ℃
Test certification:
*EN55022:2010 (RE) Band Width: 120KHz Frequency Range: 30MHz to 1000MHz
*EN61000-4-2:2001 (ESD) Air discharge voltage:± 8KV contact discharge voltage:± 4KV
Criterion: B Level 2
*EN61000-4-3:2006 (RS) 3V/m (80-1000MHz) Criteria: A Level 2
*Test Standards: EN1122:2001 EPA3050B, EPA3052 EPA3540C, EPA3060A
*Testing item: Pb Cd Hg Cr6+PBBs
*Test Results: N.D
The networking structure of the profibus dp redundant fiber optic repeater implementation
