GE IS220PAOCH1A Analog Output Module

GE IS220PAOCH1A is a process analog output module for GE Mark VIe distributed turbine control system. It converts digital control commands from the main controller into standard analog signals to drive field control valves, actuators and regulating devices, serving as the analog control output interface for turbine control loops.

This module supports multiple analog output signal types including 4-20mA current and 0-10V voltage, with high-precision D/A conversion and channel isolation. It communicates with the controller via Ethernet, supporting redundant network configuration. It is widely used as spare replacement parts for gas and steam turbine control cabinet maintenance and retrofit in power plants.

Main Specifications

1. Brand: GE; Model: IS220PAOCH1A; Type: Process Analog Output Module
2. Compatible System: Mark VIe Speedtronic Turbine Control System
3. Output Signal: 4-20mA current, 0-10V voltage; High-precision D/A conversion
4. Channel Isolation: Galvanic isolation per channel; Communication: Ethernet
5. Redundancy: Support redundant network configuration; Indicator: LED status indicators
6. Operating Temp: -40℃ ~ +70℃; Humidity:5%~95% non-condensing
7. Supply Status: Spare analog output module for Mark VIe turbine control cabinet

Core Functions

1. Convert digital control commands from controller into standard analog output signals.
2. Drive field control valves, actuators and regulating devices for turbine process control.
3. High-precision D/A conversion ensures accurate and stable analog output for critical loops.
4. Per-channel galvanic isolation suppresses interference and prevents cross-channel fault propagation.
5. Built-in self-diagnosis to detect output circuit faults and report to main controller.
6. Ethernet communication with redundant network support for high reliability data exchange.

Application Scenarios

1. GE Mark VIe gas turbine and steam turbine control cabinets in power generation plants.
2. Analog control output for turbine speed regulation, fuel control and steam valve positioning.
3. Replacement of defective analog output modules in existing Mark VIe control racks.
4. Spare parts inventory for power plant electrical and automation maintenance teams.
5. Retrofit and upgrade of legacy GE Speedtronic Mark V / Mark VI turbine control systems.
6. Distributed analog output expansion for combined-cycle power generation and industrial drives.

FAQ

1. Q: What is GE IS220PAOCH1A?
   A: It is a process analog output module for GE Mark VIe turbine control system, converting digital commands into analog signals to drive field control valves and actuators.
2. Q: What does PAOC stand for?
   A: PAOC stands for Process Analog Output Channel, the dedicated analog output interface module for Mark VIe distributed control platform.
3. Q: What output signal types are supported?
   A: It supports 4-20mA current and 0-10V voltage analog outputs, with per-channel galvanic isolation for industrial field applications.
