GE IC752SPL013-BA Operator Interface Panel

GE IC752SPL013-BA is a dedicated operator interface panel designed for GE EX2100 digital excitation control system. It serves as local HMI for power plant generator excitation units, enabling operators to view real-time operating parameters, adjust excitation setpoints and check system alarm information on site.

This panel is equipped with a 16-character alphanumeric display and 12 physical function keys for local operation and troubleshooting. It communicates with the EX2100 controller via HDLC bus. It is widely used as spare replacement parts for power plant excitation cabinet maintenance and retrofit projects.

Main Specifications

1. Brand: GE; Model: IC752SPL013-BA; Type: Excitation System Operator Interface Panel
2. Compatible System: GE EX2100 Digital Excitation Control System
3. Display: 16-character alphanumeric LCD; Keypad: 12 function buttons
4. Communication: HDLC diagnostic bus; Power supply: 24VDC ±10%
5. Mounting: Panel cutout installation on excitation control cabinet door
6. Operating Temp: -20℃ ~ +60℃; Humidity: 5%~95% non-condensing
7. Supply Status: Spare local HMI panel for EX2100 excitation cabinet maintenance

Core Functions

1. Real-time display of generator voltage, excitation current, reactive power and other key parameters.
2. Local manual adjustment of excitation setpoint and AVR control parameters on site.
3. Alarm message display and fault code query for excitation system troubleshooting.
4. HDLC bus communication to exchange data with EX2100 excitation controller.
5. Supports local operation lockout protection to prevent unauthorized parameter modification.
6. Panel mounting design, easy to remove and replace during cabinet maintenance.

Application Scenarios

1. GE EX2100 excitation control cabinets for steam, gas and hydro generators in power plants.
2. Local on-site operation and parameter monitoring of generator excitation control units.
3. Replacement of damaged operator panels for existing EX2100 excitation systems.
4. Spare parts inventory for power plant electrical and automation maintenance teams.
5. Retrofit and upgrade of legacy generator excitation control systems.
6. On-site fault diagnosis without relying on remote DCS or SCADA system.

FAQ

1. Q: What is GE IC752SPL013-BA?
   A: It is local operator interface HMI panel specially used for GE EX2100 generator excitation control system for on-site parameter monitoring and operation.
2. Q: What is the communication method with EX2100 controller?
   A: It adopts HDLC diagnostic bus to realize real-time data interaction between the panel and excitation controller.
3. Q: What does suffix BA mean?
   A: BA represents hardware revision code of the operator panel, indicating specific component and firmware version.
