GE DS200TCEAG1B Analog I/O Board

The GE DS200TCEAG1B is a plug‑in analog input and output board for GE Mark V Speedtronic turbine control systems. It acquires analog measurement signals and outputs control signals for turbine regulation.

This board communicates with the main controller via the rack backplane and integrates onboard diagnostic LEDs for fault indication. It is widely used as replacement spare parts for power plant turbine cabinet maintenance and system upgrading projects.

Main Specifications

• Brand: GE; Model:DS200TCEAG1B; Type:Analog I/O Circuit Board
• Installation:Plug‑in board, installed inside GE Mark V turbine control rack
• Function:Analog signal acquisition, control signal output, backplane data exchange, fault monitoring
• Communication:High‑speed data interaction with main CPU through rack backplane bus
• Feature:Built‑in diagnostic circuit, LED operation and fault status indicators
• Cooling:Natural convection cooling, suitable for long‑term continuous cabinet operation
• Operating Environment:0℃ ~ +60℃, 5%‑95% RH non‑condensing, industrial anti‑vibration design
• Certifications:Compliant with GE Mark V gas and steam turbine control system technical standards

Core Functions

• Receive analog signals of temperature, pressure and vibration from field transmitters and terminal boards.
• Convert analog signals into digital data and transmit measurement values to the main controller.
• Convert control instructions from CPU into analog output signals to drive field actuators.
• Carry out real‑time self‑diagnosis of onboard hardware and signal circuit abnormal conditions.
• Display running status and faults via LED indicators to simplify on‑site troubleshooting.
• Directly ｒｅｐｌａｃｅ failed original boards to restore analog measurement and control loops.

Application Scenarios

• Analog acquisition and control unit for GE Mark V steam turbine and gas turbine control racks.
• Critical spare I/O board for power generation turbine control cabinet overhaul and maintenance.
• Retrofit and spare replacement for aging Mark V racks and defective analog board upgrade projects.
• Process signal collection and actuator driving hardware of thermal power and combined cycle units.
• Analog monitoring and regulation component of large‑capacity industrial turbine control systems.

• Global aftermarket spare supply for maintenance teams servicing GE Mark V series control hardware.
