ABB XUD194 3BHE018137R0001是PCS6000中压变频装置配套RCI-Box远程控制接口盒，属于传动调试专用外设单元。它接收主控送出的内部数字测量信号，转换成模拟信号输出至示波器，无需在变频器内部搭接探头即可观测内部变量。

ABB XUD194 3BHE018137R0001 is RCI-Box remote control interface unit matched with ABB PCS6000 medium voltage converter, a dedicated accessory for drive commissioning. It receives internal digital measurement data from main controller and converts to analog signals for oscilloscope, without physical probes inside the converter.

通道配置通过PCS6000人机界面自由选择，单台最多支持8路信号同步监测，供电为24VDC，是传动调试、震荡排查、参数整定的重要工具，多用于矿山、冶金、电力存量PCS6000项目维保。

Signal channels are selected freely on PCS6000 HMI, one unit supports up to 8 channels synchronous monitoring. It runs on 24VDC power supply. It is essential tool for drive tuning, oscillation troubleshooting and parameter calibration for legacy PCS6000 drives in mining, metallurgy and power plants.

Main Specifications 技术参数

• 1. Product Series / 产品系列：ABB PCS6000 RCI-Box Commissioning Unit

• 2. Part Numbers / 型号编码：XUD194 3BHE018137R0001 (Remote Control Interface Box)

• 3. Function Type / 类型：PCS6000调试信号转换接口盒

• 4. Key Features / 特性：Max 8 analog output channels, HMI signal selection, 24VDC supply, PCS6000 dedicated

• 5. Mounting / 安装：独立便携式盒体，光纤连接变频器主控

Core Functions 核心功能

• 1. 数字信号转模拟信号，把变频器内部计算量转为示波器可采集波形。
  Digital to analog conversion, transfer internal calculated variables into oscilloscope readable waveforms.

• 2. 最多8通道同步输出，可同时观测电流、电压、转速、调节器误差等变量。
  Up to 8 channels simultaneous output for current, voltage, speed and regulator error monitoring.

• 3. 光纤链路和PCS6000主控通讯，高压侧与调试侧电气隔离，保障调试安全。
  Fiber communication with PCS6000 main controller, galvanic isolation between high voltage side and test side.

• 4. 通道选择在PCS6000 HMI上完成，硬件无需跳线改动，切换便捷。
  Channel selection fully operated on PCS6000 HMI, no jumper change required for fast signal switching.

• 5. 用于闭环调节器整定、谐振排查、启动波形记录等传动深度调试工作。
  Support closed-loop regulator tuning, resonance detection and startup waveform capture for advanced drive service.

Application Scenarios 应用场景

• 1. 矿山、冶金、水泥PCS6000中压变频器现场调试、震荡故障排查。
  On-site commissioning and oscillation troubleshooting for PCS6000 medium voltage drives in mining, metallurgy and cement.

• 2. 大功率传动系统年度检修，调节器参数复核、动态性能测试。
  Annual overhaul of high power drive systems, regulator parameter verification and dynamic performance test.

• 3. 海外PCS6000项目售后维保配套工具备件供货。
  Spare supply of service tool for after-sales maintenance of overseas PCS6000 projects.

• 4. 传动工程师实验室调试、新程序波形对比验证。
  Lab commissioning for drive engineers and waveform comparison test for new control firmware.

• 5. 存量PCS6000系统改造升级时的动态响应观测与控制优化。
  Dynamic response observation and control optimization during retrofitting of existing PCS6000 units.
