ABB TP830‑1 3BSE018115R1 Terminal Base Unit

The ABB TP830‑1 (3BSE018115R1) is a terminal base unit for ABB AC800M controller hardware platform. It serves as physical carrier and wiring interface for CPU module, providing back‑plane signal routing, field wiring terminals and mechanical positioning for controller modules inside automation rack.

This rack‑mount base supports hot‑swap compatible module installation, reliable signal transmission and power distribution. It is an essential aftermarket spare for maintenance, overhaul and retrofitting of AC800M DCS racks used in power, chemical and pulp‑paper industrial sites.

Main Specifications

• Brand: ABB; Model:TP830‑1 3BSE018115R1; Type: Controller Terminal Base Unit
• Applicable System: ABB AC800M series DCS controller rack hardware
• Function: Mechanical mounting, signal routing, power distribution, field wiring interface for matching CPU module
• Feature: Standard rack slot installation, support module hot‑swap operation, reliable signal connection
• Installation: Slot‑mount inside AC800M standard automation rack cabinet
• Power: Pass‑through power distribution from rack back‑plane
• Operating Environment: 0℃ ~ +60℃, 5%‑95% RH non‑condensing
• Certifications: CE compliant for industrial DCS automation applications

Core Functions

• Provide standardized mechanical mounting position for corresponding AC800M CPU controller module.
• Realize internal back‑plane signal routing and power supply distribution for the inserted controller unit.
• Offer external wiring terminals for field signal connection and ground‑link processing of controller hardware.
• Support hot‑swap replacement of upper‑level controller module without whole‑rack power‑off operation.
• Guarantee stable electrical connection between controller module and rack back‑plane bus during long‑term operation.
• Cooperate with other rack components to complete hardware configuration of AC800M DCS control cabinet.

Application Scenarios

• Controller base component for ABB AC800M DCS automation rack systems.
• Hardware supporting unit for process control cabinets in power plant, chemical, metallurgy and pulp‑paper industries.
• Retrofit and spare replacement for legacy TP830‑series terminal‑base‑unit rack hardware systems.
• DCS cabinet overhaul, hardware reconstruction and faulty terminal‑base replacement projects.
• Spare‑parts inventory for DCS system integrators and industrial automation engineering contractors.

• Global aftermarket spare supply for technical teams maintaining ABB AC800M DCS automation hardware.
