ABB DSQC658 3HAC025779‑001 Robot Devicenet Board

ABB DSQC658 (3HAC025779‑001) is a DeviceNet communication interface board for ABB IRC5 robot controller. It establishes DeviceNet fieldbus connection between robot controller and external slave devices, realizing bidirectional data interaction between robot system and remote I/O modules, drives and field instruments.

This board is installed inside IRC5 controller cabinet, equipped with standard DeviceNet bus interface and status diagnosis LED indicators. It supports standard DeviceNet protocol configuration, widely used as replacement spare parts for automobile manufacturing, logistics handling and industrial robot workstation maintenance and retrofit projects.

Main Specifications

• Brand: ABB Robotics
• Model: DSQC658, Part No: 3HAC025779‑001
• Product Type: DeviceNet Communication Interface Board
• Applicable System: ABB IRC5 Robot Controller
• Fieldbus Protocol: DeviceNet
• Interface: Standard DeviceNet bus connector
• Installation: Internal board card inside IRC5 control cabinet
• Diagnostic: LED indicators for communication and module status
• Certification: UL, CE industrial compliance certification
• Operating Temperature Range: 0°C ~ +55°C

Core Functions

• Act as DeviceNet fieldbus interface for ABB IRC5 robot controller
• Realize data exchange between robot main control unit and DeviceNet slave peripheral equipment
• Connect remote I/O modules, frequency converters, actuators and other third‑party slave devices
• Support DeviceNet bus parameter configuration via robot controller software
• Front‑panel LED indicators reflect network running status and communication fault alarm information
• Internal board‑card structure for quick disassembly and replacement during robot maintenance work
• Transmit robot output instructions and feed back field device status signal to robot system
• Realize bus‑type wiring to reduce on‑site discrete wiring workload of robot workstation
• Built‑in hardware diagnosis detects communication bus short‑circuit and abnormal connection faults
• Provide reliable fieldbus connection foundation for ABB robot peripheral automation workstation

Application Scenarios

• Automotive workshop ABB IRC5 robot workstation DeviceNet bus control cabinets
• Logistics handling and palletizing robot peripheral I/O and drive communication projects
• Metal processing industry welding, cutting robot automation station control systems
• Packaging production line multi‑device interconnection robot workstation application scenarios
• Factory assembly workshop robot cooperating with third‑party automation equipment projects
• Robot workstation renovation, communication board replacement and function upgrade projects
• IRC5 robot controller maintenance and spare‑parts backup for existing production lines
• ABB robot spare‑parts inventory and on‑site robot workstation maintenance supporting projects
