ABB 5SHX10H6004 3BHB003230R0101 IGCT Power Module

The ABB 5SHX10H6004 3BHB003230R0101 is an integrated gate‑commutated thyristor (IGCT) power module for medium‑voltage converters. It combines high switching speed and low conduction loss, and serves as the core power switching component of large industrial frequency conversion and power conversion systems.

This high‑power semiconductor module adopts compact packaging design and has reliable short‑circuit withstand capability. Original production has been discontinued. It is widely supplied as aftermarket spare parts for power plant converters, metallurgical medium‑voltage drives and energy conversion cabinet maintenance and retrofit projects.

Main Specifications

1. Brand:ABB; Model:5SHX10H6004, Part No:3BHB003230R0101; Type:IGCT High‑Power Semiconductor Module
2. Device Type:Integrated Gate‑Commutated Thyristor with gate drive unit
3. Feature:High voltage rating, fast turn‑off speed and strong short‑circuit protection performance
4. Cooling Mode:Designed for liquid cooling or forced air cooling in medium‑voltage converter cabinets
5. Application Target:Medium voltage variable frequency drives and static power conversion equipment
6. Installation:Standard module assembly, fixed inside high‑power converter power stacks
7. Supply Status:Original production discontinued, available as tested surplus or refurbished spare parts

Core Functions

1. Realize high‑voltage and high‑current power switching in medium‑voltage frequency converter power stacks.
2. Convert DC power into adjustable AC output to control large medium‑voltage motors.
3. Work with gate drive units to complete fast turn‑on and turn‑off of high‑power circuits.
4. Withstand short‑circuit current for a short time and avoid instantaneous breakdown during equipment faults.
5. Cooperate with snubber circuits to restrain voltage spikes and improve converter operation stability.
6. Act as the main power switching core of large‑capacity medium‑voltage power conversion systems.

Application Scenarios

1. Medium‑voltage frequency converters, large wind power converters and static reactive power compensation devices.
2. Spare IGCT module replacement and routine maintenance of existing ABB medium‑voltage converter racks.
3. Technical renovation and reliability upgrade of aging large‑capacity power conversion cabinets.
4. On‑site troubleshooting and replacement of damaged power semiconductors on heavy‑duty production units.
5. Spare‑parts stocking for system integrators and medium‑voltage converter maintenance contractors.
6. Global aftermarket spare supply for technicians maintaining obsolete ABB IGCT power conversion hardware.

FAQ

1. Q:What is the difference between 5SHX10H6004 and 3BHB003230R0101?
   A:5SHX10H6004 is the IGCT module model, and 3BHB003230R0101 is the official ABB spare part number.
2. Q:Can this IGCT module be used for low‑voltage inverter transformation?
   A:No, it is designed for medium‑voltage high‑power converters and not suitable for low‑voltage occasions.

3. Q:Is this high‑power IGCT module still in original production?
   A:ABB has stopped manufacturing this model, only tested surplus and refurbished spare units are available.
