ABB PCD235C101 3BHE057901R0101 UNITROL 6000 Exciter Control Module

ABB PCD235C101 3BHE057901R0101 is exciter control module for UNITROL 6000 excitation system on AC 800PEC platform.
Send Inquiry
Description
Argument
Products Description
ABB PCD235C101 3BHE057901R0101 | UNITROL 6000 Exciter Control Module

ABB PCD235C101 3BHE057901R0101 UNITROL 6000 Exciter Control Module


ABB PCD235C101,物料号3BHE057901R0101,是UNITROL 6000励磁系统配套励磁控制模块,运行于AC 800PEC平台,采用FPGA+RISC双核架构,满足电力电子高速实时控制需求。

ABB PCD235C101 3BHE057901R0101 is exciter control module for UNITROL 6000 excitation system on AC 800PEC platform. FPGA plus RISC core delivers high-speed deterministic power electronic control.

PCD235C101 3BHE057901R0101.jpeg

模块承担AVR自动电压调节、晶闸管桥触发脉冲生成、励磁电流闭环调节与励磁侧故障保护,通过ModuleBus背板高速通讯,逻辑侧与功率回路电气隔离,是电厂同步发电机组励磁柜核心备件。

It executes AVR regulation, thyristor firing pulse generation and field current closed-loop control. High-speed ModuleBus backplane communication and galvanic isolation make it a critical spare for generator excitation cabinets.

PCD235C101 3BHE057901R0101 (3).jpeg


Main Specifications 技术参数

  • 1. Product Series / 产品系列:ABB UNITROL 6000 + AC 800PEC Platform

  • 2. Part Numbers / 型号编码:PCD235C101 | 3BHE057901R0101

  • 3. Function Type / 类型:Exciter Control Module 励磁控制模块

  • 4. Key Features / 特性:FPGA+RISC core, AVR regulation, thyristor pulse output, ModuleBus, galvanic isolation

  • 5. Compatibility / 配套:UNITROL6000 excitation rack, ABB control software, generator CT/PT


Core Functions 核心功能

  • 1. AVR自动电压闭环调节,高精度控制励磁电流,稳定发电机机端电压与无功输出。
    AVR closed-loop voltage regulation, precise field current control to stabilize generator terminal voltage and reactive power.

  • 2. FPGA高精度晶闸管触发脉冲输出,控制励磁整流桥,实现快速励磁增减响应。
    FPGA high-resolution firing pulse generation for thyristor rectifier, fast excitation boost and de-boost response.

  • 3. 励磁系统故障监测与保护逻辑,支持过流、失磁、过励等励磁限制保护功能。
    Excitation fault monitoring and protection logic, including overcurrent, loss of excitation and overexcitation limits.

  • 4. ModuleBus高速背板总线,同机架内模块实时数据交互,同步励磁控制链路。
    High-speed ModuleBus backplane bus for real-time data exchange and synchronous excitation control.

  • 5. 电气隔离设计,功率侧与控制侧隔离,提升抗干扰能力,适配电站强电磁环境。
    Galvanic isolation between power and logic circuits, strong EMC performance for power station environment.


Application Scenarios 应用场景

  • 1. 火电汽轮发电机UNITROL6000励磁柜备件更换,AVR主调节通道维护。
    Spare replacement for steam turbine generator UNITROL6000 cabinet, AVR main channel maintenance.

  • 2. 水电水轮发电机组、燃气轮发电机励磁系统,无功调节与电网调压。
    Hydro and gas turbine generator excitation systems for reactive power control and grid voltage support.

  • 3. 海外电站EPC励磁成套项目,励磁控制柜配套核心备件供货。
    Core spare supply for overseas power EPC excitation cabinet packages.

  • 4. 存量UNITROL6000励磁系统改造维护,替换故障模块,复用原有励磁程序。
    Legacy UNITROL6000 retrofit, replace faulty module and reuse existing excitation parameters.

  • 5. 自备电厂、生物质电站同步发电机励磁调节控制单元。
    Excitation control unit for captive power plants and biomass power station synchronous generators.


FAQ 常见问答

Q: PCD235C101 和 PCD235A 是否可以直接互换?

A: 硬件架构与固件版本不同,不能直接替换,更换前需要核对版本、励磁程序及背板兼容性。

Q: 配套调试软件是什么?

A: 使用ABB UNITROL调试工具,可进行励磁参数整定、脉冲测试、限制曲线配置与录波查看。


Similar Models 相似型号

PCD235A 3BHE032025R0101

PCD235B

3BHE024577R0101

3BHE028959R0101

3BHE057901R0102
