Product Description
The 1786-RPFPXLB is a Rockwell Automation industrial ControlNet fiber repeater module. It supports ControlNet photoelectric conversion and long-distance network extension, breaking copper cable transmission distance limits. With full electrical-optical isolation, it resists electromagnetic interference and eliminates ground loop signal attenuation, ensuring low-latency, stable data transmission for industrial automation control systems.
This module features professional signal regeneration and shaping to correct distorted bus signals and optimize network stability. Adopting plug-and-play transparent transmission design, it requires no complex configuration for fast network expansion and easy maintenance. Its rugged industrial structure enables reliable 24/7 continuous operation in harsh industrial field environments.
Main Specifications
- Full Part Number: 1786-RPFPXLB; Product Type: Industrial ControlNet fiber repeater and network extension module
- Applicable System: Allen‑Bradley ControlNet fieldbus systems, industrial automation control networking platforms
- Core Function: ControlNet signal photoelectric conversion, long-distance relay extension, signal shaping and noise suppression
- Transmission Principle: Regenerates and optimizes fieldbus signals to eliminate attenuation and waveform distortion
- Isolation Performance: Complete electrical and optical isolation, effectively suppressing ground loop and electromagnetic interference
- Network Adaptability: Transparent transmission design, compatible with standard ControlNet communication protocols
- Deployment Feature: Plug-and-play operation without complex programming, supporting rapid network expansion
- Signal Stability: Low-latency signal regeneration, ensuring real-time and reliable bus data transmission
- Diagnostic Performance: Built-in network link status monitoring for quick fault judgment and maintenance
- Environmental Performance: Industrial-grade rugged structure, wide temperature resistance, vibration and interference resistance
- Compatibility: Fully matched with Rockwell ControlNet series controllers, adapters and networking accessories
Core Functions
- Acts as a dedicated fiber relay extension unit for industrial ControlNet fieldbus network systems.
- Converts electrical bus signals to optical signals to achieve long-distance industrial network transmission.
- Regenerates and shapes attenuated bus signals to ensure stable and complete data transmission.
- Provides full isolation protection to improve network anti-interference ability and system safety.
- Supports rapid network expansion and cross-region bus signal interconnection for field devices.
- Guarantees long-term low-delay, error-free and stable operation of industrial ControlNet communication networks.
Application Scenarios
- Long-distance workshop cross-area ControlNet network extension and signal relay transmission scenarios
- High-electromagnetic-interference industrial environments requiring isolated bus network transmission
- Large-scale automated production line ControlNet network expansion and signal optimization projects
- Petrochemical, power and heavy industry fieldbus network stability upgrading and reconstruction
- Replacement and performance improvement of aging repeaters for Rockwell ControlNet systems
