YOKOGAWA AAI141-H50是横河CENTUM VP、CENTUM CS3000 DCS配套16通道模拟量输入卡件，型号后缀H代表支持HART协议，50为标准非防爆版本。卡件接收现场二线制、四线制变送器4-20mA电流信号，将模拟量转换为数字量上传至FCS现场控制站，支持回路断线检测。

YOKOGAWA AAI141-H50 is a 16-channel analog input module for Yokogawa CENTUM VP and CENTUM CS3000 DCS. Suffix H indicates HART protocol support, and 50 means standard non-explosion-proof type. It receives 4-20mA signals from 2-wire and 4-wire transmitters, converts analog signals to digital data for FCS controller and supports wire break detection.

模块通道之间无隔离，系统侧耐压500V AC 1分钟，支持ESB总线冗余配置，可热插拔维护，搭载24位ADC保证采集精度。适配ANB10S、ANB11S节点机架，是流程工业存量DCS系统高频替换备件。

There is no isolation between channels, with 500V AC 1min dielectric strength on system side. It supports ESB bus redundant configuration and hot swap maintenance. 24-bit ADC ensures high accuracy, and it fits ANB10S, ANB11S node racks, widely used as spare for legacy DCS systems.

Main Specifications 技术参数

• 1. Product Series / 产品系列：YOKOGAWA CENTUM VP / CS3000 DCS I/O Module

• 2. Part Numbers / 型号编码：AAI141-H50 (16CH HART Analog Input Module)

• 3. Function Type / 类型：4-20mA HART模拟量输入卡件

• 4. Key Features / 特性：16 channels, HART communication, ±0.1% FS accuracy, ESB bus, redundant support

• 5. Mounting / 安装：ANB10S, ANB11S node unit rack installation

Core Functions 核心功能

• 1. 采集压力、液位、流量、温度变送器4-20mA模拟电流信号。
  Collect 4-20mA analog signals from pressure, level, flow and temperature transmitters.

• 2. 支持HART双向通讯，远程读取仪表参数、修改量程、在线设备诊断。
  Support two-way HART communication for remote parameter reading, range adjustment and instrument diagnosis.

• 3. 回路断线检测、通道故障报警，故障信息上传DCS操作站。
  Loop break detection and channel fault alarm, send fault information to DCS operator station.

• 4. ESB总线通讯，支持冗余配置，在线热插拔，减少停机维护时间。
  ESB bus communication, redundant configuration and hot swap to reduce downtime.

• 5. 高精度24位模数转换，稳定采集现场工艺变量用于闭环控制。
  High-precision 24-bit ADC for stable process variable acquisition for closed-loop control.

Application Scenarios 应用场景

• 1. 石油化工、油气、电厂、水处理CENTUM系列DCS系统信号采集。
  Signal acquisition for petrochemical, oil & gas, power plant and water treatment CENTUM DCS.

• 2. 流量、压力、液位、温度等工艺参数连续监测与闭环调节。
  Continuous monitoring and closed-loop regulation of flow, pressure, level and temperature.

• 3. 存量CENTUM CS3000、CENTUM VP项目备件替换、系统扩容改造。
  Spare replacement and system expansion for legacy CENTUM CS3000 and VP projects.

• 4. 配套HART智能仪表接入，实现仪表远程管理与预测性维护。
  Connect HART smart transmitters for remote instrument management and predictive maintenance.

• 5. 海外自动化项目备件供货，配套横河DCS组态调试支持。
  Spare supply for overseas automation projects with Yokogawa DCS configuration support.
