Westinghouse 1C31194G02 Digital Output Module

The Westinghouse 1C31194G02 is a digital output module developed for Westinghouse distributed control systems. It receives logic commands from the main controller and outputs switching signals to drive field actuators, solenoid valves and contactors, realizing on-site equipment sequence and interlock control.

This module adopts optoelectronic isolation design to resist industrial electromagnetic interference. Equipped with channel status LED indicators, it supports long-term stable operation, widely used as replacement spare parts for overhaul and upgrade of DCS systems in power and petrochemical industries.

Main Specifications

• Brand: Westinghouse (Emerson)
• Model: 1C31194G02
• Product Type: DCS Digital Output Module
• Operating Power: 24 VDC
• Optical isolation between internal circuit and field side
• LED indicators for each channel working status
• Installation: Standard DIN rail mounting inside control cabinet
• Operating Temperature Range: -20°C ~ +60°C
• Protection Grade: IP20 indoor cabinet use
• Compatible with Westinghouse legacy DCS rack system

Core Functions

• Convert control instructions from DCS main controller into field digital switching output signals
• Control solenoid valves, contactors and other actuators for process sequence control
• Opto-isolation structure prevents field surge interference from damaging main control hardware
• Front panel LED lights help engineers quickly judge channel operating and fault status
• Maintain reliable signal output for safety interlock of critical production equipment
• Modular structure allows convenient disassembly and rapid on-site replacement during maintenance
• Ensure stable operation under complex conditions of vibration, temperature change and dust
• Perfectly matched with Westinghouse DCS rack, power supply and related controller modules
• Support system capacity expansion to increase field switch control points of automation system
• Continuously operate for long periods to meet uninterrupted production process requirements

Application Scenarios

• Power plant steam turbine auxiliary equipment sequence control systems
• Petrochemical continuous production pump and regulating valve control racks
• Oil & gas compressor station and pipeline safety interlock control platforms
• Water treatment plant pump sets and electric valve automatic control systems
• Pulp & paper production line auxiliary machinery monitoring and control units
• Metallurgical furnace auxiliary equipment interlock control cabinets
• Chemical reactor safety protection and actuator control systems
• Offshore oil platform auxiliary equipment distributed control equipment
• Transformation, maintenance and spare parts replacement of old Westinghouse DCS systems
• Industrial DCS digital output module stock and emergency replacement projects
